Description
Jual TOA Power Amplifier ZA-2060 (60 Watt) harga terbaru 2020 di SOUNDCCTV.COM Specialist teknisi Sound System TOA di Depok.
Power Source |
220 – 240 V AC, or 24 – 30 V DC |
Rated Output |
60 Watt |
Power Consumption |
72 W (AC Operation EN60065)
4 A (DC operation at rated output) |
Frequency Response |
50 – 20,000 Hz (±3 dB) |
Distortion |
Less Than 1% at 1 kHz, 1/3 rated power |
Input |
MIC 1 – 3: -60 dB* (1.0mV), 600 Ω, balanced, phone jack
AUX 1,2: -20 dB*(100mV), 10 kΩ, unbalanced, RCA pin jack |
Output |
Speaker out: Balanced (floating)
High impedance: 170 Ω (100 V), 83 Ω (70 V)
Low impedance: 4 Ω (15.5 V)
Rec out: 0 dB*(1.0V), 600 Ω, unbalanced, RCA pin jack |
Phantom Power |
DC +21 V (MIC 1) |
S/N Ratio |
More than 60 dB |
Tone Control |
Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz |
Muting |
MIC 1: Mutes other input signals by 0 – 30 dB attenuation |
Indicator |
Power LED, signal LED, peak LED |
Finish |
Panel: ABS resin, black
Case: Steel plate, black |
Dimensions |
420 (W) × 101 (H) × 280 (D) mm (16.5″ × 4.0″ × 11.0″) |
Weight |
7 kg (15.43 lb) |
Informasi selengkapnya ketersediaan produk dan pengadaan produk TOA kuantias banyak, hub/ chat:
+62 87857190654 | Spesifikasi lengkap
ZA-2060
