Description
Power Source |
220 V AC, or 12 V DC |
Rated Output |
30 Watt |
Power Consumption |
34 W (AC operation at IEC60065) |
Current Consumption |
4.5 A (DC operation at rated output) |
Frequency Response |
50 Hz – 20 kHz |
Distortion |
1 % or less at 1 kHz, 1/3 rated power |
Input |
MIC 1 – 3: -60 dB* (1.0 mV), 600 Ω, unbalanced, phone jack
AUX: -24 dB* (60 mV), 10 kΩ, unbalanced, RCA pin jack |
Output |
Speaker out: Floating balanced
High impedance: 330 Ω (100 V)
Low impedance: 4 Ω (11 V) |
S/N Ratio |
60 dB or more (MIC 1 – 3)
70 dB or more (AUX) |
Tone Control |
Bass: -10 dB at 100 Hz
Treble: -10 dB at 10 kHz |
Indicator |
Power LED, Signal LED |
Finish |
Panel: ABS resin, black
Case: Steel plate, black |
Dimensions |
350 (W) × 100 (H) × 240 (D) mm (13.78″ × 3.94″ × 9.45″) |
Weight |
3.5 kg (7.72 lb) |
Informasi selengkapnya ketersediaan produk dan pengadaan produk TOA kuantias banyak, hub/ chat:
+62 87857190654 | Spesifikasi lengkap & Kegunaan Amplifier
ZA-230 W
