Description
Jual Speaker TOA ZS-F2000BM harga terbaru 2020 di SOUNDCCTV.COM, Agen / Distributor resmi TOA Depok.| Lampiran | Jenis bass-reflex |
|---|---|
| Input Terukur | 60 W (impedansi tinggi) |
| Kapasitas Penanganan Daya | Kebisingan terus menerus berwarna merah muda: 60 W (impedansi rendah) Program berkelanjutan: 180 W (impedansi rendah) |
| Nilai Impedansi | Garis 8 Ω 100 V: 170 Ω (60 W), 330 Ω (30 W), 670 Ω (15 W), 3,3 kΩ (3 W) Garis 70 V: 83 Ω (60 W), 170 Ω (30 W) , 330 Ω (15 W), 670 Ω (7,5 W), 3,3 kΩ (1,5 W) |
| Kepekaan | 92 dB (1 W, 1 m) at installation in 1/2 free sound field 93 dB (1 W, 1 m) at installation in 1/2 free sound field (with horn adapter) |
| Frequency Response | 65 Hz – 20 kHz, -10 dB at installation in 1/2 free sound field |
| Crossover Frequency | 2.5 kHz |
| Directivity Angle | Horizontal: 110゜, Vertical: 100゜ Horizontal: 80゜, Vertical: 80゜ (with horn adapter) |
| Speaker Component | Low frequency: 20 cm (8″) cone-type High frequency: 25 mm (1″) dome tweeter |
| Input Terminal | Push-in terminal |
| Finish | Enclosure: HIPS, black Punched net: Surface-treated steel plate, black, paint Joint bracket, wall bracket: Steel plate, t2.0, black, paint Speaker bracket: Die-cast aluminum, black, paint |
| Dimensions | 244 (W) × 373 (H) × 235 (D) mm (9.61″ × 14.69″ × 9.25″) |
| Weight | 7,4 kg (16,31 lb) (termasuk braket yang disediakan) |
| Tambahan | Braket speaker… 1, Braket sambungan… 1, Braket dinding… 1, Sekrup pemasangan braket… 1 set, Adaptor klakson… 1, Sekrup pemasangan adaptor klakson… 4 |
| Pilihan | Braket pemasangan di langit-langit: ZY-CM20B (digunakan untuk pemasangan speaker horizontal), Braket kluster: ZY-CL20B, Dudukan speaker: ST-16A |
